XRotor X11 Plus Drone Brushless Motor – HOBBYWING High Power, Electric Motor For Agricultural drones

Name: XRotor X11 Plus Drone Brushless Motor – HOBBYWING High Power, Electric Motor For Agricultural drones
Brand: United UAV
Price: 327.00 USD
Availability: InStock

Limited-Time Offer

UnitedUAV Hobbywing |

Copy

00 d

00 h

00 m

$327.00 USD

Shipping calculated at checkout.

Stock Adequate！Ready to ship

Estimated delivery: Jun 02 - Jun 06

Payment and security

Your payment information is processed securely.

View details

Description

Care Instructions

Shipping & Returns

Description

The HOBBYWING XRotor X11 Plus is a high-efficiency drone motor built for demanding aerial applications. Designed for low voltage, high power performance, it supports 15–18kg take-off weight per rotor and ensures precise throttle response through dual PWM and CAN signal control.

Equipped with advanced Multiple Intelligent Protection V2.0, it instantly handles overcurrent or stall events within 270ms, keeping flights safe and stable. The IPX6 waterproof brushless motor features enhanced corrosion resistance, upgraded thermal dissipation, and a reinforced heat structure that outperforms the X11-18S.

The built-in fault storage system enables easy data retrieval via DATALINK, helping operators analyze flight issues efficiently. With reliable drone electric motor design and superior cooling, the X11 Plus delivers consistent thrust and efficiency for professional UAV applications.

XRotor X11 PLUS brushless drone motor CAD model showing internal structure and dimensions

The HOBBYWING XRotor X11 Plus delivers exceptional performance for heavy-lift UAVs. Designed for maximum power efficiency, it provides up to 37kg thrust per rotor with advanced cooling, IPX6 protection, and intelligent flight safety features — making it one of the most reliable drone brushless motors on the market.

Product Name	XRotor X11 PLUS
Specifications
Max Thrust	37kg/rotor (54V, Sea Level)
Recommended Takeoff Weight	15–18kg/rotor (54V, Sea Level)
Recommended Battery	12–14S (LiPo)
Operating Temperature	0~50℃
Total Weight	2490g
Ingress Protection	IPX6
Rated Power Input	2500W
Rated Power Output	2130W
Motor
KV Rating	85rpm/V
Stator Size	111×18mm
Powertrain Arm Tube Outer Diameter	50mm
Bearing	Bearings imported from Japan
ESC
Recommended LiPo Battery	12–14S (LiPo)
PWM Input Signal Level	3.3V / 5V
Throttle Signal Frequency	50–500Hz
Operating Pulse Width	1050–1950μs (Fixed)
Max. Input Voltage	61V
Max. Input Current (Short duration)	150A (With Good Heat Dissipation)
BEC	No
Propeller
Diameter × Pitch	43×14
